주문을 받아서 만들어진 고가 처분 할 수있는 전자 담배 Lipo 건전지 UFX 601539 5C 3.7V 300mAh 리튬 폴리머 배터리

$1.50
In stock
SKU
UFX 601539 5C

가격 : US $ 1.2-1.5 / 암페어
Min. 주문 : 2,000 암페어
주문 하시려면 저희에게 문의하십시오!

     원산지 : 중국 광동
     유명 상표 : UFX
     모델 번호 : 601539 5C
     유형 : 리튬 폴리머
     명목상 전압 : 3.7V
     크기 : 6 * 15 * 41mm
     공칭 용량 : 300mAh
     제품 이름 : UFX 601539-5C 리튬 폴리머 배터리
     보증 : 1 년
     무게 : 6.1g
     사이클 수명 : 500 회
     신청 : 처분 할 수있는 전자 담배
     인증 : CE / ROHS / MSDS / UN38.3
     지불 : Paypal.TT.Escrow.Western Union
     최대 충전 전류 : 1C



리튬 이온 배터리


일회용 전자 담배 용 300mAh 배터리

601539 5C 3.7V 300mAh 리튬 폴리머 배터리

주문을 받아서 만들어진 고가 5C 300mAh Lipo 건전지

Product Parameters

No.

Item

General Parameter

Remark

1

Rated Capacity

Typical

320mAh

Standard discharge(0.2C C5A) after Standard charge

Minimum

300mAh

2

Nominal Voltage

3.7V

Mean Operation Voltage

3

Voltage at end of

3.0V

Discharge Cut-off Voltage

Discharge

4

Charging Voltage

4.2±0.03V



5

Internal Impedance

≤225mΩ

Internal resistance measured at AC 1KHZ after 50% charge

The measure must uses the new batteries that within one week after shipment and cycles no more than 5 times

6

Standard charge

Constant Current 0.2C5A

Charge time : Approx 6h

Constant Voltage 4.2V

0.01 C5A cut-off

7

Standard discharge

Constant current 0.2 C5A



end voltage 3.0V

8

Fast charge

Constant Current 0.5C5A

Charge time : Approx 2.5h

Constant Voltage 4.2V

0.01 C5A cut-off

9

Fast discharge

Constant current 0.5C5A



end voltage 3.0V



10

Maximum Continuous Charge Current

1 C5A



11

Maximum Continuous Discharge Current

5C5A



12

Operation Temperature Range

Charge: 0~45

60±25%R.H.

Bare Cell

Discharge: -20~60



13

Storage Temperature Range

Less than 1 year: -20~25

60±25%R.H.

less than 3 months: -20~40℃

at the shipment state

14

Pack  Dimension

High: max41mm

Width: max15mm
Thickness: max6mm

Initial  Dimension
