무선 마우스 용 Lipo 배터리 UFX 601248 250mAh 3.7V 리튬 폴리머 배터리

$1.20

In stock

SKU

UFX 601248

가격 : US $ 1.2-1.5 / 암페어
Min. 주문 : 2,000 암페어
주문 하시려면 저희에게 문의하십시오!

무선 마우스 용 배터리 UFX 601248 250mAh 3.7V 리튬 폴리머 배터리

601248 250mAh 3.7V 리튬 폴리머 배터리

UFX 601248 250mAh 3.7V 리튬 폴리머 배터리

601248 250mAh 3.7V 배터리

250mAh 3.7V 리튬 폴리머 배터리

250mAh 무선 마우스 용 Lipo 배터리

601248 3.7V 리튬 폴리머 배터리

Product Parameters

No.	Item	General Parameter		Remark
1	Rated Capacity	Typical	260mAh	Standard discharge(0.2C C₅A) after Standard charge
		Minimum	250mAh
2	Nominal Voltage	3.7V		Mean Operation Voltage
3	Voltage at end of	3.0V		Discharge Cut-off Voltage
	Discharge
4	Charging Voltage	4.2±0.03V
5	Internal Impedance	≤215mΩ		Internal resistance measured at AC 1KH_Zafter 50% charge
				The measure must uses the new batteries that within one week after shipment and cycles no more than 5 times
6	Standard charge	Constant Current 0.2C₅A		Charge time : Approx 6h
		Constant Voltage 4.2V
		0.01 C₅A cut-off
7	Standard discharge	Constant current 0.2 C₅A
		end voltage 3.0V
8	Fast charge	Constant Current 0.5C₅A		Charge time : Approx 2.5h
		Constant Voltage 4.2V
		0.01 C₅A cut-off
9	Fast discharge	Constant current 0.5C₅A
		end voltage 3.0V
10	Maximum Continuous Charge Current	1 C₅A
11	Maximum Continuous Discharge Current	1C₅A
12	Operation Temperature Range	Charge: 0~45℃		60±25%R.H.
				Bare Cell
		Discharge: -20~60℃
13	Storage Temperature Range	Less than 1 year: -20~25℃		60±25%R.H.
		less than 3 months: -20~40℃		at the shipment state
14	Pack Dimension	High: max50mm Width: max12mm Thickness: max6mm		Initial Dimension
